CUB Explorer

Description

MEDIUM

UP TO 4

OFF ROAD

BALL WEIGHT 140KG

ATM 1400KG

TARE 827KG

Introducing the Cub Explorer, an affordable yet fully-equipped off-road camper designed for budget-conscious adventurers who value Australian craftsmanship. This robust camper comes standard with a Smev 2-burner stove, sink, stainless steel pantry, and a silent winch, making it perfect for any escapade. Built with an all-Australian galvanised steel chassis and canvas, it’s engineered to withstand challenging terrains and conditions. With updated powder-coated locker doors and striking graphics, the Explorer combines durability with style, ready to take you anywhere your heart desires.

The Cub Explorer is your ultimate Aussie-made off-roader, equipped with features to enhance your outdoor experience. With a 5-year warranty on both the canvas and suspension/chassis, plus Australia-wide support, you can embark on your journey with confidence. Inside, you’ll find a medium density foam mattress and ample under-bed storage to keep your essentials organised. The Explorer boasts modern conveniences like a 100AH AGM Battery and numerous power outlets, ensuring you’re prepared for extended adventures. Embrace the call of the wild with the Explorer, a combination of reliability, functionality, and affordability.

Enquire Now

Body Specs

ATM: 1400kg
Ball Weight: 140kg*
Body Length: 2.23m
Body Width: 1.70m
Open Length Inc. Drawbar: 6.58m
Tare: 827kg*
Towing Height: 1.62m
Towing Length: 4.35m

Brakes & Wheels

Holroyd Square Axle: 45mm
Brakes: 10″ Electric
Spare Wheel: Rear Wind Up (Steel)
Tyres: 235/75R15 Marshal AT 51
Wheel Type: 15 x 6 Black Steel (6/139.7 PCD)

Drawbar

4kg Gas Bottle: 1
4kg Gas Bottle Holder: 2
Additional Clamp for AL-KO Jockey Wheel: Standard
AL-KO Ball Hitch: 50mm Off Road
AL-KO Jockey Wheel: 250mm
Drawbar: 100 × 50 × 3.0mm
Fridge Box and Slide: Standard
Fridge Box Size (95 l): W=560mm L=930mm H=515mm
Galvanised Steel Stoneguard: Standard
Jerry Can Holder: 2
Silent Winch: Standard

Suspension & Chassis

AL-KO Wind Down Legs: 2
Australian Galvanised Steel Chassis: Standard
Rear Recovery Points (2400kg Rating): Standard
Shock Absorbers: Single
Suspension: AL-KO 6 Leaf Shackle

Inside Fittings

Bed Size: 2130 x 1350 x 90mm
Mattress: Medium Density Foam
Under Bed Storage: Standard

Outside Fittings

Alloy Roof Rack: Standard
Roof Rack Stabiliser Legs Adjustment Length: 180mm
Roof Tie Down Points: Standard
Pole Carrier Kit: Standard

Drawers: 2
Ezy-Clean Kitchen Top: Standard
Mixer Tap: Standard
Smev Stainless Steel Stove & Sink: 2 Burner
Stainless Steel Pantry: Standard

100% Australian Made Tent Using Wax Converters Dynaproof Canvas: Grey
Aluminium Awning Poles: Standard
Bed Side Canvas Window Flaps & Midge-Proof Fly Screen: Standard
Deluxe Awning: Standard
Internal Front Canvas Window & Zipper: Standard

12V Pump: 10 L/min
Locking Water Filler: Standard
Water Gauge: Standard
Water Tank: 80L

240V External Inlet (15A): Standard
240V External Outlet: Standard
240V Internal Double Outlet: Standard
100AH AGM Battery: 1
Battery Charger IC25RV (240V): Standard
Battery Charger IDC25X (12V): Standard
12V External Outlet (ACC): 2
12V Internal Outlet (ACC): 2
12V Master Isolation Switch: Standard
12V Resettable Fuse for Fridge: Standard
LED Floor Lighting: Standard
LED Strip Lights (ACC Plug) 1.2 Metre: Standard
LED Sensor Lights – Underbed: Standard
LED Bedside Lights: 2
Twin USB – Bedside: 2
Solar Input (Anderson Plug) – Suits Unregulated Solar Panel: Standard

* All model specification details are subject to change.
The tare and ball weights are a guide only and will change depending on drawbar layout and accessories fitted to your caravan. Please discuss with a member of our team prior to purchase. Each Cub Camper is weighed on completion of build and a precise written weigh bridge certificate is then provided.
Please note that all images displayed on this page are for illustrative purposes only and may include optional equipment and features. Please confirm final specifications and features with DBC prior to purchase.
